Genie 34ft Electric Knuckle Boom Lift


Genie Z-34/22N 34ft Electric Knuckle Boom Lift

The Genie® Z®-45/25J DC electric and bi-energy articulating boom lifts offer quiet, emission-free operation in the most sensitive work environments. They’re 48V DC machines with a diesel-powered generator acting as a 100-amp battery charger, making these articulating boom lifts ideal for indoor and outdoor applications.

With this electric lift at only 1.42m wide with a stowed height of 2.26m making this machine compact enough to fit through many narrow spaces while allowing for a maximum raised deck of 10.52m.

Why choose the Genie Z-34/22N 34ft Electric Knuckle Boom Lift?

  • 2WD travels at 4.8 km/h with 30% gradeability
  • Large 1.83 m all-steel platform lifts up to 227 kg
  • Self-leveling platform features a 160° hydraulic rotation for Genie Z-45/25 J models
  • Self-leveling platform features 180° powered rotation for precise positioning and easy operation

Brand New Equipment purchased from Auslift comes with the manufacturer’s warranty.


Working Height 12.52m
Platform Height 10.52m
Horizontal Outreach 6.78m
Stowed Height 2.00m
Width 1.47m
Weight 5216kg
