Electric Knuckle Boom Lifts
Choose your platform height below
| Type | Working Height | Horizontal Reach | Up and Over | Length | Width | Height | Weight |
|---|---|---|---|---|---|---|---|
| 34' Diesel | 12.4m | 6.6m | 5.25m | 5.64m | 1.8m | 2.15m | 5640kg |
| 34' Electric | 12m | 6.6m | 5.25m | 5.43m | 1.34m | 1.99m | 5910kg |
| 45' Diesel | 16m | 9.1m | 6.6m | 6.5m | 2.3m | 2.2m | 7100kg |
| 45' Electric | 15m | 8.45m | 6.6m | 6.6m | 1.5m | 2m | 7300kg |
| 56' Diesel | 17.3m | 10.6m | 6.6m | 7.6m | 2.3m | 2.2m | 8120kg |
| 60' Diesel | 20.46m | 12.1m | 8.07m | 8.82m | 2.44m | 2.54m | 10069kg |
| 80' Diesel | 25.6m | 16.2m | 6.8m | 12m | 2.38m | 2.67m | 15950kg |
| 125' Diesel | 38.1m | 19.25m | 18.44m | 11.45m | 2.49m- 3.81m | 3.05m | 19958kg |
4WD Diesel Knuckle Boom Lifts
Choose your platform height below
| Type | Working Height | Horizontal Reach | Up and Over | Length | Width | Height | Weight |
|---|---|---|---|---|---|---|---|
| 34' Diesel | 12.4m | 6.6m | 5.25m | 5.64m | 1.8m | 2.15m | 5640kg |
| 34' Electric | 12m | 6.6m | 5.25m | 5.43m | 1.34m | 1.99m | 5910kg |
| 45' Diesel | 16m | 9.1m | 6.6m | 6.5m | 2.3m | 2.2m | 7100kg |
| 45' Electric | 15m | 8.45m | 6.6m | 6.6m | 1.5m | 2m | 7300kg |
| 56' Diesel | 17.3m | 10.6m | 6.6m | 7.6m | 2.3m | 2.2m | 8120kg |
| 60' Diesel | 20.46m | 12.1m | 8.07m | 8.82m | 2.44m | 2.54m | 10069kg |
| 80' Diesel | 25.6m | 16.2m | 6.8m | 12m | 2.38m | 2.67m | 15950kg |
| 125' Diesel | 38.1m | 19.25m | 18.44m | 11.45m | 2.49m- 3.81m | 3.05m | 19958kg |
4WD Diesel Straight Boom Lifts
Choose your platform height below
| Type | Working Height | Horizontal Reach | Length | Width | Height | Weight |
|---|---|---|---|---|---|---|
| 46'Diesel | 15.44m | 12.3m | 8.42m | 2.3m | 2.21m | 6650kg |
| 66'Diesel | 22.32m | 18.3m | 10.21m | 2.42m | 2.57m | 12700kg |
| 85'Diesel | 27.9m | 23.6m | 12.3m | 2.4m- 3m | 2.8m | 16266kg |
| 125' Diesel | 39.9m | 24.4m | 12.2m
|
2.6m-3.5m | 3.05m | 20248kg |
| 150' Diesel | 47.7m | 24.38m | 18.81m | 2.49m-3.81m | 3.05m
|
21773kg |
| 185' Diesel | 58.57m
|
24.38m
|
19.44m | 2.49m-5.03m
|
3.05m
|
27351kg |
